China LED Flat Panel Light manufacturer

24W Slim Surface Mounted LED Panel Light Rimless Back Lighting 2000LM Aluminum

Product Details:
Place of Origin: China(mainland)
Brand Name: ADO
Certification: ROHS CE FCC 3C
Model Number: AD-RL-PAL-24W
Payment & Shipping Terms:
Minimum Order Quantity: One Carton
Price: Negotiation
Packaging Details: 20 pieces in one carton
Delivery Time: 5 - 8 work days
Payment Terms: PayPal, Western Union, T/T, L/C
Contact Now

Detail Information

Power: 24W Voltage: AC85-265V
Lighting: Back Lighting Lumen: 2000LM
Installation: Surface Mounted Material: Aluminum
High Light:

thin led light panel

,

ultra slim led panel light

Product Description



24w LED Slim Panel Light Surface Mounted Rimless Back Lighting 2000LM Aluminum





1. 24W LED Slim Panel Light Specification:



Model AD-RL-PAL-24W
Power 24W
CCT 3000K, 4000K, 6500K
Input Voltage AC85-265V
LED Brand Taiwan Epistar
Lumen 2000LM ± 50 LM
Color Rendering Index 80RA
LED Chip SMD2835*168LEDS
Diameter 175mm
Height 35mm
Material Aluminum(fixture)+PMMA(LGP)
Beam angle 120°
Operation temperature -20℃~+60℃
Mounting height 1-4 meters
Lighting Distance 2-3meters
Warranty 2 years
IP rank IP20





2. Description:



This LED Slim Panel Light housing is rimless, the rim/outer ring is only 1mm aluminum material, makes the lighting area is much bigger, can bring more light. Also the emitting mode is back lighting, not side lighting. The installation is surface mounted. We have round and square, power is 16w, 24w and 30w. size is 120mm, 175mm and 225mm. Height is 35mm.





3. Features:



1. High-quality aluminum shell, better heat dissipation, less light decay, longer life.

2. High-efficiency energy-saving, ultra-low power consumption, the same lighting effect is more than 80% energy saving than traditional light sources

3. LED cold light source, no radiation, no harmful elements such as mercury and lead, which is conducive to recovery and utilization, without any harm to eyes and skin.

4. Integrated with high quality aluminum shell for LED heat releasing and to ensure LED lifetime.

5. Imported light diffusion material, mercury and lead free

6. Bright light full plane output, wider light emission angle.

7. Good color rendering, soft light, uniform light spot, pure light color

8. Eco-friendly. No mercury and harmful materials

9. CE&RoHS certificated, meet the requirements of UL, SAA and RoHS compliant.





4. Application:



1. Office Lighting, Retail & Grocery Stores, Showrooms, Airports

2. Commercial Lighting, Restaurants & Hotels, Shopping malls
3. Institution buildings, Super market Lighting
4. Hospitals, Warehouses, Warehouse Lighting, Galleries





5. Advantages:



1. Thick housing, means better heat dissipation, means chip has long lifespan
2. Lifetime more than 50000hrs, providing 3 years warranty.
3. High lumen 80lm per watt ,low light decay.
4. High light transmittance>90% ,more soft light.
5. Saving 80% electricity than ordinary panel lights.

6. Certificates:CE Rosh EMC LVD




6. 6W Packing Information:



Power PCS/Carton Carton Size (CM) CBM/ CTN
16w 50 PCS 27.5*27.5*46 0.0347875
24w 20 PCS 38*38*23.5 0.033934
30w 20 PCS 48*48*23.5 0.054144


7. Delivery & Shipping:

1. Samples Delivery Time: 3-5 days
2. Official Order Delivery Time: 16 work days
3. Shipping method: DHL / Fedex / TNT / Air Shipping / Sea Shipping
4. Shipping time: 3-7 days for express/air shipping, one month by sea

5. By Express: DHL, TNT,UPS, Fedex,EMS, fast and safe way for shipping, normally 3-5 working days for delivery

6. By Air: In some area, the shipping cost by air is more favorable than by Express; 5-7 days for delivery;

7. By Sea: the most economic shipping method, but cost longer shipping time; large quantity, heavy and not urgent goods can choose this way.

8. Your shipping agent or forwarder, collect goods from our factory



8. Quality Control Capacity:



A. QC Team: 8 persons.
B. Integrated QC system is implemented in every aspect of production for 4 times strictly check. Raw materials-during productive process-finished products-after aging before pack( one by one)
C. More than 200square meters aging room for each goods aging 24hours
