Product Details:
|
|
| Place of Origin: | China(mainland) |
|---|---|
| Brand Name: | ADO |
| Certification: | ROHS CE FCC 3C |
| Model Number: | AD-MP-09-20W |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | One Carton |
| Price: | Negotiation |
| Packaging Details: | 20 pieces in one carton |
| Delivery Time: | 5 - 8 work days |
| Payment Terms: | PayPal, Western Union, T/T, L/C |
|
Detail Information |
|||
| Power: | 20W Max | LED Chip: | Epistar SMD5630 |
|---|---|---|---|
| Material: | Aluminum | Housing Color: | White Black |
| IP Grade: | IP65 | Installation: | Wall Mounted |
| Input Voltage: | AC85-265V | Warranty: | 3 Years |
| High Light: | wall mounted bulkhead light,led bulkhead light |
||
Product Description
1. Specification:
| Item No. | Description | |
| AD-MP-09-20W | Wattage | 20W (MAX) |
| Input Voltage | AC85-265V | |
| Light source | LED | |
| Lamp Luminous Efficiency(lm/w) | 80LM/W | |
| Lamp Luminous Flux(lm) | 1600LM | |
| Color Temperature(CCT) | 2700~6500k | |
| LED Chip | Epistar | |
| Emergency Function | Optional | |
| LED Type | SMD 5630 | |
| Working Temperature(℃) | -15~45℃ | |
| Ingress Protection | IP65 | |
| Size(mm) | 170*115*78 | |
| Mechanical Protection | IK09 | |
| Warranty(Years) | 3 years | |
1.High quality IP65 LED bulkhead light is made of high quality ABC+PC, AL PCB, high lumen SMD5630 and constant current driver, which make it anti-oxidation, not yellowing, longer life time and higher light efficiency. With concised design, it is suitable for many application. Meet IP65 and IK09 standard.
2. Power is adjustable. It can be maximum 30W according to heatsink.
3. Chip are optional, Citizen/CREE/BridgeLux/Epistar/Sanan; CRI>80 or CRI>90.
4. Dimmable driver are optional. It can be Triac/PWM 0~10V optional.
5. Max Lumens efficiency: 110lm/w, CRI are >70Ra, >80Ra and >90Ra optional. 3-year warranty.
6. Emergency Function is optional.
A. Waterproof and moistureproof
B. Anti-exidation
C. Safe and durable
E. Healthy eye protection
F. Easy Installation
G. Intelligent power saving
H. High configuration
