120led Ip65 Waterproof Led Light Strips Smd3014 Chip With 8mm Pcb Length

Product Details:
Place of Origin: China
Brand Name: ADO
Certification: CE ROHS UL
Model Number: A3014-120-V12
Payment & Shipping Terms:
Minimum Order Quantity: One Roll
Price: Negotiation
Packaging Details: 50 Rolls One Carton
Delivery Time: 3-7 work days
Payment Terms: T/T, Paypal, Western Union
Supply Ability: 10,000 meters per day
Contact Now

Detail Information

LED Chip: SMD3014 LED Brand: Epistar
LED Qty: 120LED CRI: 80Ra
Voltage: DC12V IP Grade: IP20 IP65 IP67 IP68
PCB Length: 8mm
High Light:

smd led strip lights

,

waterproof led light strips

Product Description



SMD3014 IP65 LED Flexible Strips Light DC12V 120LED 80Ra 8mm 9.6W




1. Description:


LED strip designs are available populated with many different types of SMD, not only in different colors and addressable or non-addressable, by different shapes, sizes, and power levels. The most common types of SMD are: 3528, single colour, non-addressable, very low power; 5050, containing three LEDs allowing for RGB and addressable strips as well as higher power levels; 2835, a newer single-color SMD having the same surface dimensions as the 3528 but a larger emitter area and a thinner design with an integrated heatsink allowing for higher power levels; 5630/5730, a newer replacement for single-color 5050 SMDs which can operate at slightly higher power levels and have high efficacy. Less common designs may have 3014, 4014, 7020, 8020, or other SMDs.





2. Products Specification:



Model A3528-120-W-V12 Warranty 3 Years
LED Type SMD3014 Life Span 30000 hours
LED Qty (pcs/m) 120 Beam Angle 120 degree
CCT W, WW, NW LED Brand Epistar
LED Brightness 7-8LM IP Grade IP20 IP65
CRI 80Ra Dimmable Yes
SDCM <5 Package 5 meters / Roll
Work Voltage DC12V PCB thickness 2oz
Peak Power 9.6W PCB Color White
Size 5000*8mm Certificate CE UL RoHS




3. Application:



LED Strips are widely used for indoor lighting and outdoor lighting.


1. Architectural decorative lighting
2. Car decoration
3. Auditorium walkway lighting
4. Backlighting for signage letters
5. Channel letter lighting
6. Emergency exit path lighting
7. Cove lighting
8. Concealed lighting





4. Features:



1. Cold light source, low heat, will not produce heat radiation on the display of goods.
2. The green lighting source does not produce harmful ultraviolet light, and is particularly suitable for lighting of cultural relics and medicines.
3. Efficient energy-saving, saving more than 65% of fluorescent lamps.
4. Long life, once installed for 10 years.
5. Used to shine gold and silver jewelry, watches and more crystal clear.
6. Low voltage operation, safe and reliable.
7. Waterproof, shockproof; low loss, long life.





5. Installation Guide:


1. Power connection method: LED lights with a general voltage of DC 12V, so you need to use the switching power supply, the size of the power supply according to the LED lamp power and connection length. If you do not want to use a power supply to control each LED strip, you can purchase a switching power supply with a relatively high power as the main power supply, and then connect all LED lights in parallel with the input power (if the wire size is not enough, you can extend it). Unified power supply from the main switching power supply. The advantage of this is that it can be controlled centrally. Inconvenient places cannot achieve the lighting effect and switch control of a single LED strip, which method can be used to measure by itself.
2. The controller connection: LED Marquee and RGB full-color light belt need to use the controller to achieve the changing effect, and each controller's control distance is not the same, in general, the simple controller control distance is 10 to 15 meters, remote control controller control distance is 15 to 20 meters, the longest can be controlled to a distance of 30 meters. If the LED light strip has a long connection distance and the controller cannot control the length of the light strip, a power amplifier is required to perform tapping.
3. Pay attention to the connecting distance of the LED light strips: Generally, the 3528 series LED light strips have a connection distance of up to 20 meters. The 5050 series LED strips have a maximum connection distance of 15 meters. If this connection distance is exceeded, the LED strips are prone to heat, and the lifetime of the LED strips is affected during use. Therefore, when installing, it must be installed according to the manufacturer's requirements. Do not overload the LED lamp.





120led Ip65 Waterproof Led Light Strips Smd3014 Chip With 8mm Pcb Length 0
