IP20 3 W COB LED Spot Bulbs For Restaurant 240LM 6000K AC12V DC12V 45 Degree 30mm

Product Details:
Place of Origin: China
Brand Name: ADO
Certification: CE ROHS
Model Number: AD-SPW01-3W
Payment & Shipping Terms:
Minimum Order Quantity: One Carton
Price: Negotiation
Packaging Details: 100 Pieces One Carton
Delivery Time: 3-7 work days
Payment Terms: T/T, Paypal, Western Union
Supply Ability: 10,000 pcs per day
Contact Now

Detail Information

LED Type: COB LED 3W LED Quantity: 1pcs
Voltage: DC12V AC12V Material: Aluminum
Base: MR16 Dimmable: Yes
High Light:

energy saving light bulbs


led spotlight bulbs

Product Description


Dimmable MR16 3W COB LED Spot Bulbs 240LM 80Ra 6000K AC12V DC12V 45 degree 30mm



1. 3W MR16 LED Spot Bulb Light Technical Data:


Model AD-SPW01-3W Brand ADO
Size D35mm*H50mm Origin China
Power 3W Beam Angle 45 degree
Material Aluminum LED Brand Epistar
LED Type COB 3W*1pcs MOQ One Carton
PFC 0.6 LED Driver IC constant
CRI 80RA Name LED Spot Bulb
Lumen 240LM Application Indoor lighting
Voltage DC12V Base MR16
CCT 3000K/6500K IP Level IP20
Warranty 2 Years Life Span 30000 hours
Packing Quantity 100pcs Certificate CE RoHS



2. Description:


This item led spot light size is very small, the diameter is 30mm, height is 50mm. housing material is aluminum, which is good for heat dissipation. The COB led chip is Taiwan Epistar brand with 80RA, power can make 3w, luminous efficiency is about 80-90LM per wattage. And the base can make MR16, E27 and GU10, this led spot light beam angle is 45 degree. Dimmable version and non dimmable version are optional.



3. LED Spot Light Specification:


Input Voltage: DC12V
Input Power: 3W
LED Type: 1pcs*3W
Luminous Flux: 280-300LM
Color Temperature: 2700K-5000K
CRI: 80Ra (90Ra can customize)
Lifetime: 40,000-50,000hours
IP Rating: IP20
Housing Color: Sliver
Beam angle :  60° / 45° / 30°



4.  LED Spot Bulb Features:


1. Energy saving can reach above 80%;

2. Long life span equals to 50,000 hours;

3. High light effect and low maintenance costs;

4. Low heat output and protection for heat-sensitive objects

5. UV and IR free light, free of mercury and hazardous materials.



5. Quick Details:


A.  3W Replacing 25W halogen lamp

B.  High efficient LED light source--- COB LED Chip from Taiwan Epistar

C.  With GU10 / MR16 /E14 / E27 different lamp bases

D.  Color rendering index of 80Ra and 90lm/W

E.  Long life properties--lowers maintenance costs by reducing re-lamp frequency

F.   Warranty 2 years

G.  CE RoHS EMC LVD certificate approved

H.   Long life span with 30000 hours



6. Application:

1. Task lighting for cabinets and boards in your homes, restaurants, andkitchens or any other places where accent lighting is required;

2. Replacement bulbs for general lighting, especially for museum.

3. lampe berger malaysia for homes, offices, restaurants, supermarket, hotels, malls, warehouses etc;



7.  Different base dimension:


E14 : 50mm( diameter) X78mm(length)

E26 : 50mm( diameter) X 62mm( length)

E27 : 50mm (diameter) X 63.2mm (length)

MR16 : 50mm( diameter) X 53mm( length)

GU10 : 50mm ( diameter) X 62mm ( length)

GU5.3 : 50mm ( diameter) X 63mm ( length)



8. RFQ:


Q1. Are you a manufacturer or a trading company?

A1. We are a factory in Guangzhou, with OEM&ODM&Customization available.


Q2. Do you have the ability to do independent research and development?

A2. Five people in the engineering department support our company to do independent research. And willlaunch new products on a regular basis.


Q3. Can you give us a favorable discount ?

A3. Of course, a favorable discount will be offered if the quantity is sizable.


Q4. Are your products conforming to our standards?

A4.Yes,  our products pass the testings as you require, e.g.:CE, RoHS,etc.


Q5. How do you control the quality ?

A5. We control the product quality by IQC, three tests on production lines, and 100% aging testing before packaging.
